On-site Hypochlorite generation system

One of the most effective, resilient & durable system in the region

4kg Salt 95%

+

7Kwh

=

1kg active Chlorine

Safety meets Efficiency

  • Non - Hazardous lowstrength solution at a stable concentration of 0.8%.

  • Compatible with all salt types.

Low Operating Costs

  • On - demand Chlorine production.

  • Integrated Compact Design. Simple maintenance.

  • Easy to replace spare parts and low cost.

Automatic Process Control

The system is designed to operate automatically, run at the optimum salinity to increase power efficiency, extend cell life and power - save shutdown if sodium hypochlorite is not in use.

Specifications

Model Dimenson (LxWxH) (mm) Power capacity (kW/h) Salt Consumption (kg/h) Water Consumption (l/h) Product Concentration (g/l)
SFJ1500 3200x2400x1700 7.5 4.8 310 6.5 - 8
SFJ1000 3200x2400x1700 5 3.3 230 6.5 - 8
SFJ500 3200x2400x1700 4 2.55 120 6.5 - 8
