Continuous Backwash Filter

Ideal technology for tertiary nutrient removal.

Available for customization to fit application requirements.

Superior filtrate quality

  • Preliminary treatment of raw water with high suspended solids content.

  • Deep media bed allows for heavy duty performance.

Low operational & maintenance costs

  • Continuous cleaned sand bed.

  • No backwash pumps: low energy consumption.

  • No moving parts: reduce maintenance.

  • Automatic operation process.

Using Micro - Organisms

  • To remove organic compounds from contaminated and polluted water.

  • Allow for mechanical, chemical and biological filtration processes.

  • Reduce chemical requirements by 20 -30% Over conventional treatment.

Specifications

Model Capacity (M3/d) Dimensions (mm) Upper flow (m3/m2/h) Height (mm) Inlet Pipe (mm) Outlet Pipe (mm)
SFCF.1000 1000 D2800 x 1 6.7 6400 DN100 DN150
SFCF.5000 5000 D2800 x 5 6.7 6400 DN250 DN350
SFCF.10000 10000 D2800 x 10 6.7 6400 DN350 DN500
SFCF.20000 20000 W5000 x L12500 6.7 6400 DN500 x 2 DN800
SFCF.30000 30000 W5000 x L15000 6.7 6400 DN650 x 2 DN1000
SFCF.50000 50000 W10000 x L15000 6.7 6400 DN800 x 2 DN1200
